Details

48" overall length, Live Rail: 24" x 2-1/2" x 1/2" standard - call for custom rail sizes and lengths

Specifications

  • Certificate of Conformance: NON-NTEP
  • Type: Monorail
  • Scale Capacity: 2,000 lb standard - custom capacities up to 4,000 lb
  • Scale Length: 48” standard - custom lengths available
  • Live Rail: 24” x 2-1/2” x 1/2” standard - custom rail sizes and lengths available
  • Weighbridge Material: 304 stainless steel
  • Finish: All exposed surfaces are sand blasted to a clean, consistent appearance
  • Load Cell: Stainless steel (IP67) and hermetically sealed (IP68HS), 350 Ohms, 3.0mV/V 2K capacity: (2) 1,000 lb
  • Junction Box: NEMA 4X stainless steel junction box with signal trim summing board

Material

  • Stainless Steel
Loading Resources ...

Frequently Asked Questions

  • 3-Years on weighbridge steel structure
  • 2-Years on load cells, junction box, and summing board

Industries
